Aircraft control cables are the vital tendons connecting your commands to the flight surfaces. When they have issues, safety is compromised. Troubleshooting them effectively is a critical skill for pilots, mechanics, and aircraft owners. Here’s a practical guide:
1. Safety First!
Secure the Aircraft: Ensure the aircraft is properly chocked, tied down, and the parking brake is set.
Control Locks: Install control locks or have someone physically hold the controls in a neutral position to prevent unexpected movement.
Battery/Electrical: Disconnect the aircraft battery if working near electrical systems or components moved by the cables.
Eye Protection: Wear safety glasses – broken wire strands are sharp and dangerous.
2. Visual Inspection: Your First Line of Defense
Look Along the Entire Run: Follow each cable from its control end (yoke/stick/pedal) to its termination point (bellcrank, quadrant, control surface horn). Look for obvious damage.
Check for Fraying & Broken Wires: Pay close attention to areas passing through pulleys, fairleads, guides, and bulkhead openings. Look for:
Individual broken wires sticking out (“meathooks”). Even one broken wire is cause for concern.
General fraying or a “fuzzy” appearance.
Kinks or sharp bends in the cable.
Examine Pulleys & Fairleads:
Ensure pulleys rotate freely without binding or excessive play.
Check for cracks, chips, or worn grooves in pulleys.
Verify fairleads (guides) are smooth, not cracked, and correctly aligned. Look for signs of cable rubbing.
Inspect Terminations (Swages & Fittings):
Look for cracks, corrosion, or deformation in the swaged fittings.
Ensure the cable is seated correctly within the fitting; no slipping should be evident.
Check for corrosion where the cable enters the fitting.
Look for Corrosion & Contamination:
Check for rust, white oxidation, or green corrosion on the cable or fittings.
Look for signs of dirt, grease, or other contaminants that could trap moisture or cause abrasion.
Check Cable Routing:
Ensure the cable isn’t rubbing against structure, other cables, or components.
Verify adequate clearance throughout the entire run, especially where it passes through bulkheads or structure.
Look for signs of chafing on adjacent surfaces or on the cable’s protective sleeve (if present).
3. Functional Check: Feeling for Problems
Operate the Controls: Slowly and smoothly move the controls (yoke, stick, pedals) through their full range of motion. Feel for:
Binding or Sticking: Does the control feel rough, catch, or require excessive force at any point?
Excessive Slack/Sloppiness: Is there more free play than usual before the control surface moves?
Uneven Effort: Does the force required to move the control feel inconsistent?
Listen: Pay attention for any unusual sounds like scraping, grinding, or clicking during control movement.
Observe Movement: Have a helper watch the control surfaces while you move the controls. Ensure they move smoothly, symmetrically (for ailerons/elevator), and through their full range without hesitation or binding.
4. Measurement & Specific Checks
Cable Tension: Refer to the aircraft’s specific Maintenance Manual for the correct tension specifications and measurement procedures (usually using a tensiometer). Incorrect tension (too loose or too tight) can cause premature wear, slop, or excessive control forces.
Wear Measurement: Use a wear gauge (go/no-go gauge) specifically designed for the cable diameter. Insert it onto the cable in areas passing through pulleys or fairleads. If the gauge closes completely around the cable, the cable is worn beyond limits and must be replaced.
Corrosion Inspection: If corrosion is suspected, carefully clean the area (following approved procedures) and reinspect. Deep pitting or significant corrosion warrants cable replacement.
5. Common Culprits & What They Mean
Broken Wires/Fraying: Immediate replacement required. Indicates fatigue, overstress, or severe abrasion.
Kinks: Usually requires replacement. A kink significantly weakens the cable and creates a stress concentration point.
Corrosion: Severity dictates action. Light surface corrosion might be cleaned and monitored per the manual. Significant pitting or corrosion requires replacement.
Binding/Sticking: Often caused by:
Damaged, dirty, or misaligned pulleys/fairleads.
Improper cable routing causing rubbing.
Lack of lubrication (where applicable – check the manual! Some cables are “dry”).
Internal cable strand breakage jamming inside the housing.
Excessive Slack: Can be caused by:
Cable stretch (normal over time, requires re-tensioning per schedule).
Worn or loose control system components (bushings, bearings, rod ends).
Improper initial rigging.
High Tension/Stiff Controls: Can be caused by:
Overtightened cables.
Binding in pulleys or guides.
Frozen or seized control surface hinges/bearings.
Cable routing issues creating excessive friction.
When in Doubt, Seek Expertise!
Know Your Limits: Troubleshooting is one thing; repair and replacement are often complex tasks requiring specific tools, techniques (like proper swaging), and regulatory compliance.
Consult the Manual: The Aircraft Maintenance Manual (AMM) is your ultimate authority for inspection criteria, allowable damage, tension specs, and procedures.
Involve an A&P Mechanic: Aviation cables are safety-critical. If you find any damage, suspect a problem, or lack the tools/expertise, consult a qualified Airframe & Powerplant (A&P) mechanic immediately. They can perform definitive inspections and necessary repairs or replacements in accordance with FAA regulations and manufacturer instructions.
Conclusion:
Regular, thorough visual inspections combined with attentive functional checks are key to catching aviation cable issues early. Understanding what to look for (fraying, corrosion, kinks, wear) and what operational problems indicate (binding, slack, stiffness) empowers you to identify potential failures. Always prioritize safety, refer to your specific aircraft manuals, and never hesitate to involve a certified mechanic for repairs or when uncertainty arises. Vigilance with cables is vigilance for safe flight.
